ZT10 Integrated DTH Drill Rig

Kaishan is a world-leader in the supply of mining and rock excavation tools and equipment. In addition to supplying your operation with the premium brand of rock tools, our range of added services and digital solutions support your drilling operations, everyday – all year round. Overall, we do everything we can to ensure you get maximum life, productivity and performance from your rock tools, so that you can achieve the lowest total drilling costs. With Kaishan Rock Tools Services, you will never work alone.

Description
Inquiry

1. Kaishan ZT10 series using its single power to drive the screw air compressor and drilling rig hydraulic system at the same time, compared with the separated DTH drilling rig, the comprehensive fuel consumption and energy saving are 35%, and the maintenance cost is reduced by 50%; 2. The core hydraulic components are imported from Europe. The reliable hydraulic system greatly reduces the workload of system maintenance and is convenient and practical; 3. Powerful two-speed hydraulic traveling mechanism, strong off-road capability, and large torque swing motor can easily deal with drill stuck; 4. The two-stage dry dust collection device is environmentally friendly and helps improve production efficiency; the integrated technology solves the problems of moving and long-distance management of air compressors in engineering and mining. 5. Equipped with standard plunger motor and international engineering machinery walking track, it is more powerful for climbing, more reliable in quality and high in walking efficiency.

Model name: Kaishan ZT10 Integrated DTH Drill Rig

Drill hole size: ᵠ90-130mm(standard configuration 115mm)

Drill Depth(Eco): Max.32m

Drilling rotary speed: 0-120rpm/min

Engine: Yuchai YC6L310-H300(304HP/228KW/2200rpm/min)

Drill rod library:7+1(Drill Rod Auto-connecting unloading system)

Outer Size:9300x2400x3300/3600mm

Weight of complete set: 15000 KG

Equipped air compressor:18m³/min-17bar
